Cardboard Cores

If the core is wrong, the roll is wrong. Too wide, too soft, or too damp, and you get outofshape rolls, slow winding, and rejected shipments.

Cardboard cores are a technical spec, not a catalog item. Internal diameter, wall thickness, flat crush, and moisture all depend on your material, roll weight, and machine.

Below, standard sizes, the specs that matter, and how to pick a supplier.

What Is a Cardboard Core?

It’s the tube your material winds around, and it carries the weight of the roll from the machine to the customer’s floor.

• Made from layers of paperboard wound and glued into a rigid tube
• Defined by four numbers: internal diameter, wall thickness, length, and flat crush
• Also called paper cores, industrial paper cores, or paper tubes, same product
• Comes in standard sizes (2″, 3″, 6″, 8″) or built to your spec
•  Holds the roll straight during winding, storage, and transport

MAMPACK produces paper tubes and industrial paper cores to the specification your line requires, in standard sizes and custom dimensions. Send us your specs and our technical team will get back to you.

Cardboard Cores vs Paper Cores — Is There a Difference?

Different names for the same product:

• Cardboard core, paper core, industrial paper core, and paper tube all describe the same item.
• The name changes by industry and by market, not by the product.
• MAMPACK uses “paper tubes and industrial paper cores” across all sizes and specifications.

How Cardboard Cores Are Made

Production runs through seven stages, each one controlling a different part of the final spec:

• Paper is cut into strips and wound in layers around a mandrel
• Layers are glued to build the required wall thickness
• Cores are dried to a controlled moisture level of 4 to 7 percent
• Cut to the required length
• Inspected for diameter, thickness, length, flat crush, and edge quality before delivery

Choosing the Best Rotogravure Printing Company ensures high-quality, precise, and consistent printing with advanced rotogravure technology, making it ideal for flexible packaging and demanding industrial printing applications

Standard Cardboard Core Sizes

 Four standard sizes cover most production lines. Cardboard core sizes are defined by internal diameter, wall thickness, weight, and flat crush:

Large Diameter Cores Up to 450mm

MAMPACK is the only manufacturer in the region producing cardboard cores up to 450mm in diameter:

• Produced to the same tolerance and quality standards as the standard sizes.
• Full custom manufacturing available for any dimension your line requires.
• Send your specifications and quantity and our technical team will review them.

Choosing the Best Cardboard Core Manufacturers ensures precise dimensions, consistent strength, reliable production capacity, and custom solutions tailored to packaging, printing, tape, insulation, and other industrial applications.

Cardboard Core Specifications

Nobody inspects a core until something goes wrong with the roll. These three specs are usually where it went wrong:

    Internal Diameter Accuracy

• The core has to sit on your machine’s shaft without play.
• Standard internal diameters: 50mm, 76mm, 152mm, and 204mm.
• Diameter is checked against spec before delivery.
• A diameter that is off means an unstable roll and slower winding.

    Wall Thickness and Flat Crush Resistance

Wall thickness carries the roll weight. Flat crush tells you how much pressure the core takes before it deforms:

• Wall thickness from 3mm to 20mm depending on size.
• Flat crush from 600 to 6,000 N/10cm depending on size and spec.
• Heavier rolls and higher winding tension need a thicker wall and higher flat crush.
• Both are tested before delivery.

    Moisture Content and Dimensional Stability

Moisture is what makes a core bend or change dimensions after it leaves the factory.

• Controlled moisture content of 4 to 7 percent across all sizes.
• Prevents warping and dimensional change in storage and transport.
• Cores are dried under control, not left to air dry.

Choosing the Best Insulation Cardboard Company ensures high-quality, durable, and precisely manufactured insulation cardboard solutions designed for reliable thermal and electrical insulation applications across various industrial requirements.

 Industries and Applications for Cardboard Cores

If it comes on a roll, it’s wound on a core. What changes from one industry to the next is the spec.

• Stretch film
• Aluminum foil
• Rotogravure printing
• Flexible packaging
• Textile
• Paper
• Tape and labels
• Artificial grass
• Sorting and packing stations (citrus, potatoes)
• Insulation material winding

Standard vs Custom Cardboard Cores

Standard cardboard core sizes cover most lines. When they don’t, custom cardboard cores are built to the spec you send:

When Standard Sizes Work

• Your machine takes one of the four standard internal diameters: 50mm, 76mm, 152mm, or 204mm.
• Roll weight and winding tension sit inside the standard flat crush range.
• Length is set at order, from 1cm to 10m.

When to Request Custom Manufacturing

• Your line needs a diameter outside the standard four, up to 450mm.
• Roll weight or tension calls for a wall thickness or flat crush beyond the standard range.
• A new product or a new machine, and the spec isn’t set yet.
• Send the dimensions, quantity, and how the core will be used, and our technical team reviews it before production.

Choosing the Best Large Diameter Cardboard Core Manufacturer ensures high-strength, precisely engineered cores with customized diameters, lengths, and wall thicknesses for demanding packaging, printing, winding, and industrial applications.

 How to Choose a Cardboard Core Manufacturer

Any cardboard core manufacturer can quote a size. Here’s what MAMPACK brings to the three areas that decide the supply:

Certifications and Quality Testing

• ISO certified for quality management
• Diameter, thickness, length, flat crush, and edge quality checked before delivery
• Moisture held at 4 to 7 percent under controlled drying

Production Capacity and Lead Times

• 1,000+ tons per month, with capacity to scale
• Large orders handled in short lead times
• Regular supply so the line doesn’t stop between orders

Technical Support and Sampling

• Specs reviewed against your roll weight, material, and machine before production
• Samples available before supply starts
• Over 100 staff and technicians, working since 2015

Choosing the Best Cardboard Core Manufacturer for Citrus Sorting Stations ensures precisely engineered cores with the right inner diameter, wall thickness, strength, moisture control, and straightness for reliable performance in demanding citrus sorting operations.

How to Order Cardboard Cores from MAMPACK

Ordering cardboard cores from MAMPACK starts with the spec, not the price. Send us the numbers and we’ll come back with a quote:

• Fill in the contact form on the site with your name, company, phone, email, and industry.
• In the message, include the internal diameter, wall thickness, length, quantity, and how the core will be used.
• Our technical team reviews the specifications against your roll weight, material, and line.
• You get a quote, and a sample before supply starts if you want one.
• For anything urgent, reach sales on +201224313333 or Sales@mampack.net.

In the end, the core is either right for your line or it isn’t. Send MAMPACK your specifications and quantity, and our technical team will work out the rest.
